Why Pool Filter Maintenance Matters
Your pool filter is the heart of your water circulation system. A dirty, torn, or clogged filter cartridge forces your pump to work harder, increasing your electric bill and shortening the pump lifespan. A properly maintained pool filter can reduce pump energy consumption by up to 20%.
Signs Your Filter Cartridge Needs Replacement
- Pressure gauge reads 8-10 PSI above normal: Even after cleaning, a worn-out cartridge will not drop back to baseline.
- Water flow visibly reduced at the return jet: If you can barely feel water coming back, the cartridge is restricting flow.
- Cartridge pleats are flattened or torn: The accordion-style pleats should stand upright. Flat pleats mean exhausted media.
- Cleaning does not restore white color: If the cartridge stays gray/brown after soaking, the media is permanently clogged.
- Filter is more than 2 years old: Most pool filter cartridges have a 1-2 season service life.
How to Clean Your Pool Filter Cartridge
- Turn off the pump and release pressure via the air relief valve on top of the filter tank.
- Remove the filter tank lid (for Hayward Star-Clear, turn the locking knob counter-clockwise). Lift out the cartridge.
- Hose off loose debris with a garden hose, working from top to bottom between the pleats. Do NOT use a pressure washer.
- Soak in filter cleaner for 8-12 hours to dissolve oils, sunscreen, and body lotions.
- Rinse thoroughly and inspect all pleats for damage before reinstalling.
- Lubricate the tank O-ring with silicone lubricant before closing the lid.
Filter Grid Assemblies: The DE Filter Alternative
For larger pools using Diatomaceous Earth (DE) filters, the filter element is a grid assembly rather than a cartridge. These curved plastic grids with DE powder trap particles as small as 2-5 microns -- far finer than cartridge filters (20-40 microns). DE filter grids last 3-5 years, but the plastic frames eventually become brittle and crack. When you see DE powder blowing back into the pool, your grids have failed.
Recommended Filter Products
RCX70101 Filter Cartridges (4-Pack) -- For Tiger Shark robotic cleaners. Shop Now
PLF150A Filter Cartridge -- Replaces Pentair CC150/Clean & Clear 150. Shop Now
24 Sq.ft DE Filter Grid Assembly -- Fits DEX2420DC. Shop Now
FAQ
How often should I clean my pool filter cartridge?
Clean every 2-4 weeks during peak swimming season, or whenever the pressure gauge reads 8-10 PSI above your clean baseline.
Can I run my pool without a filter cartridge?
No. Running the pump without a filter element allows debris to enter the pump impeller and plumbing, potentially causing damage.
What is the difference between a filter cartridge and a DE grid?
Cartridge filters use pleated polyester media filtering to 20-40 microns. DE filters use fabric-covered grids with DE powder filtering to 2-5 microns. DE provides better clarity but requires more maintenance.
