DIY ABS Diesel Fuel Tank for Camper Vans A Complete Under-Van Installation Guide — No Diesel Smell Inside Your Cabin 📅 July 2, 2026  |  ⏱️ 19 min read  |  🏷️ Van Build, Diesel Heat...

Why You Need a Separate Diesel Tank for Your Camper Van

If you're driving a gas-powered van but running a Chinese diesel heater (like the popular Eberspächer-style units from China), you face a common problem: your engine runs on gasoline, but your heater needs diesel fuel. The naive solution — tapping into your gas tank — isn't an option. Diesel and gasoline are chemically incompatible fuel systems, and mixing them is a serious safety hazard.

The real issue isn't just the fuel type mismatch, though. It's diesel odor. Diesel has a much stronger smell than gasoline, and if you plumb your heater into the main fuel tank, you'll get diesel fumes seeping into your camper interior. That's not just unpleasant — it can be a health and safety concern over time.

The clean solution? Install a separate dedicated diesel tank for your heater, mounted safely underneath the van, completely isolated from the cabin. This guide walks you through building and installing one using 4-inch ABS pipe — a material that's stronger, more cold-resistant, and more shock-absorbent than PVC.

This approach gives you:

• Zero diesel smell inside your camper
• A dedicated fuel supply for your heater that never touches your gas system
• Capacity of roughly 10–15 liters — enough for many nights of heating
• A completely DIY project with parts available at any hardware store

Why ABS Over PVC for a Fuel Tank?

You might wonder why we chose ABS (Acrylonitrile Butadiene Styrene) pipe instead of the more common PVC. Here's the breakdown:

For an under-van application, ABS wins on every metric that matters. Your fuel tank will be exposed to road debris, temperature swings, and constant vibration — ABS handles all of this better than PVC. And since diesel is the fuel in question (not gasoline), ABS is fully compatible.

Materials & Tools Checklist

Parts You Need

• 4-inch ABS pipe — length to fit your van's undercarriage (≈50 inches / 127cm for a Ram ProMaster)
• 4-inch ABS end caps (×2) — seal both ends of the tank
• 1-inch ABS pipe — for the filler neck stub
• 1-inch to 4-inch reducer couplings (×2) — connect filler neck to main tank body
• 1/8-inch fuel pickup tube — from your diesel heater kit (inlet from tank to fuel pump)
• 5/8-inch vent coupling — atmospheric vent at the high end of the tank
• 5/8-inch ID vent hose — routes vent line along the van frame
• 1-inch ID fuel supply hose — from tank to heater pump
• M8 rivet nuts (×4) — weld-in orrivet into frame members
• 3/4-inch galvanized pipe strapping — attaches tank to mounting brackets
• Camper seal multi-purpose foam tape — vibration dampening between tank and van body
• ABS cement + primer — for solvent welding all joints
• Diesel fuel filler cap — (ideally yellow for easy identification)
• Aluminum sheet — for rock guard fabrication (≈16 gauge)

Tools You Need

• Angle grinder or hacksaw — cutting ABS pipe to length
• Drill with 3/64" and 3/8" bits — holes for fittings and rivet nuts
• T30 Torx socket — for removing Ram ProMaster fuel line shield clips
• Rivet gun — installing rivet nuts and final assembly
• Hammer — setting clips and rivets
• Deep socket (size to match clips) — for setting press-on clips
• Penetrating oil — for stubborn hardware
• Utility knife & deburring tool — cleaning up cut pipe edges
• Marker, scribe, measuring tape — layout and marking
• Cable ties — securing fuel lines

Planning: Finding Space Under the Van

Before cutting any pipe, spend real time underneath your van with a flashlight. Here's what to look for:

1. Identify the fuel filler area — Your gas filler neck typically protrudes through the body near the rear wheel well. On a Ram ProMaster, you'll find press-on plastic clips holding the fuel line shield in place.
2. Map the frame rails — These are your attachment points. Most van frames have open C-channel sections where you can bolt or weld brackets.
3. Check rear axle clearance — The tank must clear the rear wheel well and any suspension components. On the ProMaster, a 50-inch long × 4-inch diameter tank fits nicely ahead of the rear axle.
4. Trace your fuel line route — Plan how the 1/8" fuel pickup will run from the tank forward to your heater's fuel pump location.

Step 1 — Build the Mounting Brackets

Start with the brackets before the tank. You'll need four mounting points:

1. Cut four pieces of steel (3/4" × 1/8" strap or angle) sized to wrap around the 4" ABS pipe with enough material to bolt to the frame.
2. Drill M8 holes in each bracket for the rivet nuts.
3. Install four M8 rivet nuts into your van's frame rails where the brackets will bolt. This requires access to the inner frame channel — you may need to remove the fuel line shield to reach it.
4. Before installing the tank, stick a layer of camper seal foam tape to each bracket's contact surface. This is the same material used to protect pickup beds when mounting canopies — it prevents metal-to-paint contact and dampens vibration.

Once the rivet nuts are set, you have four rock-solid anchor points. The foam tape does double duty: it protects the paint and absorbs shock from road vibration.

Step 2 — Assemble the ABS Diesel Tank

The tank body is straightforward — but precision in assembly matters for leak-free operation.

Cut the Pipe to Final Length

Start with a 6-foot length of 4" ABS. Dry-fit everything underneath the van first to find the exact final length. For a Ram ProMaster, expect around 50 inches. Every inch matters for clearance around the rear wheel.

Assemble the Components

The tank has three key openings:

1. Filler neck end — A 1" reducer coupling transitions from the 4" body to a 1" filler stub. This goes at the rear of the van, near the filler door.
2. Fuel pickup (bottom) — The 1/8" pickup tube from your heater kit exits the bottom of the tank. This must be at the lowest point for complete fuel draw-down.
3. Vent coupling (top, highest point) — A 5/8" coupling at the opposite end of the tank from the filler. This allows air to enter as fuel is drawn out.

Test for Leaks Before Installing

This is critical: cap the 1/8" pickup opening, fill the tank with water, and let it sit overnight. Any joint that seeps needs re-cementing. A leaking tank installed under your van is a nightmare to fix.

Calculate Capacity

A 50" × 4" (ID) ABS tank gives you approximately:

• Tank body: ~10.25 liters (π × r² × h = 3.14 × 5.1cm² × 127cm ≈ 10.3L)
• Filler neck dead volume: ~0.25 liters
• Total: ~10.5 liters — comparable to the internal tank that came with most Chinese diesel heaters

Step 3 — Install the Dual Filler Neck

If you're mounting a second fuel door next to your existing gas cap, this is the most challenging part — the fit is extremely tight.

1. Temporarily remove the existing gasoline filler assembly to give yourself working room.
2. Drill a second hole in the filler door housing for the diesel filler. Use a 3/64" pilot hole first, then open up with a 3/8" bit.
3. Route the diesel filler neck up through the body, feed both the filler neck and the 5/8" vent line into the filler cavity.
4. Critical: The diesel filler must go on the outside of the frame member — it cannot be sandwiched between the inner and outer panel. Route it outside the structural member, not through it.
5. Drill a 3/8" hole in the top of the diesel filler cap — this is your air inlet that lets the pump draw fuel smoothly without vapor lock.
6. Reconnect the gasoline vent line and reassemble everything. This is a very tight fit; patience is essential.

Step 4 — Mount the Tank Under the Van

With the brackets ready and the tank assembled, mounting is straightforward:

1. Set the tank into the four brackets.
2. Cut 3/4" galvanized pipe strapping to wrap around the tank — two straps per bracket, top and bottom.
3. Bolt the straps to the M8 rivet nuts you installed earlier.
4. Use cable ties to secure any slack in the fuel pickup tube so it doesn't chafe against anything.

The result should be absolutely solid — the tank should not move at all. Road vibration is constant; a loose tank will fail.

Step 5 — Route Fuel & Vent Lines

Three lines need to be routed from the tank forward to your heater:

1. 1/8" fuel pickup line — runs from the bottom of the tank forward to the heater's fuel pump. This is the most critical line: it must be fuel-rated, routed cleanly, and secured every 12–18 inches to prevent chafing.
2. 5/8" vent line — runs from the vent coupling at the top of the tank, along the frame rail, and exits somewhere discreet at the rear of the van. It must have a constant upward slope (no low spots where water can pool).
3. 1" filler neck extension — routes from the tank body up to the filler cap at body level.

Reuse existing channels in the van's factory wiring/fuel line shields wherever possible. On the ProMaster, the fuel line shield has an unused channel originally intended for the DEF tube — it fits a 1" fuel line and 5/8" vent line perfectly.

Step 6 — Build a Rock Guard

The 1/8" fuel pickup line and its fittings protrude below the tank line and sit dangerously close to the rear wheel path. A rock guard is cheap insurance.

1. Use a scrap piece of 4" ABS as a forming die to bend 16-gauge aluminum sheet to the correct radius.
2. Mark the mounting hole positions using a screw as a height reference.
3. Cut relief notches where the aluminum must clear the fuel nipple and mounting hardware.
4. Dry-fit with Cleco clamps, check alignment, then install with A4 rivets.
5. The guard should completely surround the fuel line — smooth side facing the tire, protecting against thrown gravel and road debris.

Step 7 — Test & Fill

Before calling it done:

1. Double-check all connections are tight and clamped.
2. Prime the fuel line by drawing diesel through it — you should see fuel arrive at the pump connection within seconds of turning on the heater.
3. Start the heater and let it run through a full cycle. Watch for any leaks at fittings.
4. If everything holds, clean up the fuel line routing and install a wire loom or heat-shrink over any exposed hose for UV and abrasion protection.
5. Paint the filler cap yellow (or another high-visibility color) so it's instantly distinguishable from your gas cap.

Safety Notes

• Work in a well-ventilated space. Diesel fuel emits vapors — keep sparks and open flames away.
• Never use ABS for gasoline. ABS is rated for diesel only. If you need a gasoline auxiliary tank, use something else (aluminum or steel).
• Pressure-test before first use. The water test overnight is non-negotiable — a fuel leak under a van is hard to find and dangerous.
• Route lines away from heat sources. Exhaust components and anything that gets hot must not contact fuel lines.
• Check local regulations. Auxiliary fuel tanks may have legal requirements depending on your region. Verify before registering your vehicle.

Conclusion: A $100 Solution That Actually Works

Building your own ABS diesel tank for a camper van is one of the most satisfying DIY upgrades you can make. Total parts cost is typically under $100 — a fraction of what a commercial auxiliary tank would cost — and the installation is straightforward if you're comfortable working under a van.

The key benefits are immediate: no diesel smell in your cabin, a dedicated heater fuel supply that never touches your gas system, and roughly 10+ liters of heating fuel capacity mounted safely outside the living space. For cold-weather van lifers running a Chinese diesel heater, this is the right way to do it.
