385230325 RV Toilet Vacuum Breaker Kit — Hand Sprayer — Stop Leaks & Prevent Backflow
A leaking vacuum breaker on your RV toilet doesn't just waste water — it can siphon contaminated water back into your fresh water system, cause odors, and damage your bathroom floor. The iFJF 385230325 Vacuum Breaker Kit is the correct dual-port replacement for Dometic/Sealand Traveler and VacuFlush toilets equipped with a hand sprayer. Unlike single-port alternatives, this kit includes the dedicated sprayer connection port — no adapters, no leaks, no compromises. Complete kit includes vacuum breaker body, integrated dual-seal check valve, all O-rings and gaskets, and stainless steel mounting hardware. Measures 3.25" L × 1.73" W × 3.65" H for exact drop-in fit.
Key Features
-
Hand Sprayer Compatible: Dual-port design with dedicated sprayer connection — no T-fittings or adapters that create leak points. Specifically for toilets WITH a hand sprayer.
-
Complete Kit: Vacuum breaker body (3.25"L × 1.73"W × 3.65"H), dual-seal check valve, all O-rings, gaskets, and stainless steel hardware — everything needed.
-
Backflow Prevention: Dual-seal check valve prevents contaminated water from siphoning back into your fresh water plumbing. Meets ABYC and RVIA code requirements.
-
Durable Materials: High-impact ABS body withstands years of vibration from road travel. Nitrile seals resist holding tank chemicals and marine sanitation products.
-
DIY-Friendly: 20-30 minute installation with basic hand tools. 1/2" NPT connections match factory plumbing.
Compatibility
| Brand |
Series |
Models / Notes |
| Dometic / Sealand |
Traveler |
110, 111, 210, 211, 510, 511 (with hand sprayer) |
| Dometic / Sealand |
VacuFlush |
All models with hand sprayer attachment |
⚠️ Not Sure Which Kit? If there's a coiled hose behind your toilet connected to the breaker → this is your kit. No hose → order 385316906 (no sprayer).
Specifications
| Specification |
Detail |
| Part Number |
385230325 |
| Dimensions |
3.25"L × 1.73"W × 3.65"H |
| Material |
ABS Body / Nitrile Seals / Stainless Steel Hardware |
| Connection |
1/2" NPT — Dual Port (Water Inlet + Sprayer) |
| Check Valve |
Dual-Seal, Integrated |
Symptoms of a Failed Vacuum Breaker
- Water leaking or spraying from behind the toilet pedestal — especially when the hand sprayer is used
- Continuous slow drip from the breaker housing
- Bowl fails to hold water after flushing
- Sewage odor near the toilet (backflow through failed check valve)
- Reduced sprayer pressure or water hammer when flushing
Installation Steps
- Shut off water supply to the toilet.
- Flush to relieve system pressure.
- Disconnect the hand sprayer hose and water supply line from the old breaker.
- Remove the old vacuum breaker (typically 2 screws or threaded collar).
- Clean mounting surface and inspect for cracks or damage.
- Install new breaker with supplied gaskets — 2-3 wraps of Teflon tape on threaded connections.
- Reconnect sprayer hose and water line, turn on supply, test all connections for leaks.
Why Choose iFJF?
iFJF vacuum breaker kits are manufactured to OEM Dometic/Sealand specifications with upgraded nitrile seals for extended service life — especially important in hot climates where rubber seals degrade faster. US-based support and fast shipping from our American warehouse.
Related Products
Frequently Asked Questions
Q: Does this fit toilets without a hand sprayer?
A: No. If your Sealand/Dometic toilet does NOT have a hand sprayer, you need the 385316906 (single-port) vacuum breaker kit. This 385230325 has a dedicated sprayer port.
Q: How long does installation take?
A: 20-30 minutes. Accessing the back of the toilet in tight RV bathrooms is typically the most time-consuming part. A compact mirror and headlamp make it easier.
Q: Do I need thread sealant or Teflon tape?
A: Yes. Apply 2-3 wraps of Teflon tape to male threaded connections. Do not use pipe dope or liquid sealants — they can degrade the nitrile seals.
Q: Why does my breaker leak only when I use the hand sprayer?
A: This is a classic sign of a failed check valve inside the vacuum breaker. The sprayer back-pressures the system, and a worn seal can't hold. Replacement is the fix.
Q: Will this stop sewage odors?
A: If the odor is from backflow through a failed vacuum breaker — yes. If caused by a failed floor flange seal or holding tank vent, those may need separate repair.
