CNC Billet Aluminum Fuel Filter Housing Cap — Replaces 134001 on 6.6L L5P & 3.0L LM2/LZ0 Duramax
This 134001 billet aluminum fuel filter housing cap is the direct replacement for the factory plastic cap on every GM Duramax that runs the ACDelco TP1015 cartridge filter: 2017-2026 6.6L L5P in the Silverado and Sierra 2500HD / 3500HD, and 2020-2026 3.0L LM2 / LZ0 in the Silverado and Sierra 1500. It threads into the factory housing (GM 13539472), turns with a 36mm (1-3/8") socket, seals with the large O-ring out of your ACDelco TP1015 filter kit, and torques to 25 N·m / 18 ft-lb. No adapter ring, no thread insert, no modification. The cap ships on its own — the O-rings live in the filter box, not with the cap.
Key Features
6061-T6 Billet Aluminum: CNC-machined from solid billet stock — not cast, not molded. The threads are cut, not formed, so they hold their profile through every heat cycle and every filter change.
Machined O-Ring Groove: The seal seat is cut to ±0.001" so the ring from your TP1015 kit drops in and stays put while the cap turns. An O-ring that rides up onto the threads instead of sitting in the groove is the single most common cause of a leaking housing cap.
Hard-Coat Anodized Finish: Resists road salt, diesel exposure and under-hood chemicals. It will not pit, oxidize or chalk like raw aluminum.
Correct 36mm Hex: The same size as the factory cap, so the socket you already own fits — 1-3/8" works too. No strap wrench, no pipe pliers, no chewed-up hex.
Stainless Steel Drain Screw: The drain screw sits at the low point of the inverted housing, exactly where the factory T40 screw sits. Machined from stainless steel with an integrated sealing washer — it will not seize, round out or weep after repeated water drains.
One Cap, Two Engines: The 6.6L L5P and the 3.0L LM2 / LZ0 share the same fuel filter housing and the same TP1015 element. This cap fits both, which is why it is sold as one part number instead of two.
Vehicle Compatibility
Make
Model
Years
Engine
Chevrolet
Silverado 2500HD
2017-2026
6.6L Duramax L5P
Chevrolet
Silverado 3500HD
2017-2026
6.6L Duramax L5P
GMC
Sierra 2500HD
2017-2026
6.6L Duramax L5P
GMC
Sierra 3500HD
2017-2026
6.6L Duramax L5P
Chevrolet
Silverado 1500
2020-2026
3.0L Duramax LM2 / LZ0
GMC
Sierra 1500
2020-2026
3.0L Duramax LM2 / LZ0
Chevrolet
Tahoe / Suburban
2021-2026
3.0L Duramax LM2 / LZ0
GMC
Yukon / Yukon XL
2021-2026
3.0L Duramax LM2 / LZ0
Cadillac
Escalade / Escalade ESV
2021-2026
3.0L Duramax LM2 / LZ0
Will not fit: 2016 and earlier Duramax (LML / LGH) — those trucks use a spin-on TP3018 canister and have no threaded housing cap. Also not for gasoline engines or for the DEF / diesel exhaust fluid filler.
Technical Specifications
Specification
Value
Part type
Fuel filter housing cap (housing cover)
Replaces OEM cap
134001
Matches housing
GM 13539472
Filter used
ACDelco TP1015 / GM 13539108 / 23304096
Material
6061-T6 billet aluminum
Manufacturing
CNC machined — not cast, not molded
Finish
Hard-coat anodized, corrosion resistant
Socket size
36mm (1-3/8" also fits)
Drain screw
Stainless steel, T40 Torx
O-rings included
No — cap only. New O-rings are supplied in the ACDelco TP1015 filter box
Cap torque
25 N·m / 18 ft-lb
Drain screw torque
2 N·m / 1.5 ft-lb
Weight
Approx. 0.45 lb
Why the Factory Plastic Cap Fails
The OEM cap is glass-filled nylon. Every filter change means another 18 ft-lb of torque on plastic threads that have already been through hundreds of heat cycles, from a -20°F cold start to 220°F+ under-hood temperatures while towing. The nylon loses its thread profile, and the hex starts to round. From there it fails one of three ways: the cap stops sealing and diesel weeps past the O-ring, the hex rounds out so the cap cannot be removed, or the cap cracks outright and the fuel system starts drawing air.
Air is the expensive part. The CP4.2 high-pressure pump is lubricated and cooled by the fuel it pumps — an air pocket means metal-on-metal contact inside a $1,500+ pump, and the debris it makes travels straight into the injectors. A billet aluminum cap removes all three failure modes for the cost of one filter change.
Installation — Cap Replacement With a New Filter
Allow 20-30 minutes. Work on level ground with the engine cold.
Gather the tools. 36mm 6-point socket (1-3/8" also fits), ratchet, torque wrench that reads 18 ft-lb, T40 Torx bit, pick tool, drain pan, clean diesel for lubrication, gloves, and a new ACDelco TP1015 filter.
Find the housing. The housing hangs cap-down. On 2020-2026 trucks it is mounted on the driver-side frame rail, roughly below the rear door — reachable from the ground without a lift. Mounting height and orientation vary by model year, so confirm which way the cap faces before you start. If your truck has air suspension, raise it to the highest setting and enable Service Mode first.
Clean the outside first. Wash the housing with soapy water and dry it. Never spray brake cleaner on the plastic housing — grit that gets pushed inside while the cap is off goes straight into the fuel system.
Drain the housing (optional). Crack the T40 drain screw at the low point of the cap and let the diesel run into the pan. On many trucks it only trickles — plan for roughly a quart to come out when the cap releases either way.
Remove the cap. Set the drain pan underneath, fit the 36mm socket and turn counterclockwise. Break it loose, then unwind by hand as the flow slows.
Separate the old element. The filter clips onto a stem in the center of the cap. Rock it side to side and pull it straight off — do not pry with a screwdriver against the sealing surface.
Fit the new O-rings from the filter box. Have the TP1015 filter on hand before you start. Use the pick tool to lift the old O-rings out of their grooves without scratching them. One large O-ring seals the cap; the small one lives on the center pickup tube inside the housing and seals the clean side from the dirty side. A missed small O-ring sends unfiltered fuel straight to the high-pressure pump. Lubricate each new O-ring with clean diesel — not grease, not engine oil.
Seat the large O-ring in the groove. On the new cap, the O-ring drops into the machined groove below the threads. If it sits on the threads instead, tightening will roll and pinch it, and the cap will weep within a few hundred miles. This is the mistake behind most leaking cap installs.
Assemble the new filter. Press the narrow end of the TP1015 element onto the cap stem until it clicks, and check that it stands straight rather than cocked to one side.
Pre-fill and install. Pour clean diesel into the housing to about 80% — it shortens priming. Thread the cap on by hand until the O-ring contacts, then torque to 25 N·m / 18 ft-lb. If you use the drain screw, snug it to 2 N·m / 1.5 ft-lb only; it is a sealing screw, not a structural one.
Prime the system. Keep your foot completely off the brake pedal and hold the START button for about 10 seconds to reach RUN without cranking. Release, then repeat once — the lift pump runs and pushes air out of the housing. On vehicles with a key, cycle to ON for 10 seconds twice instead. Then brake on and start the engine.
Check for leaks. Let the engine idle, then look at the cap threads and drain screw for any dampness. A dry cap after 2-3 minutes of running is a sealed cap.
Reset the monitor. In the driver information center, open Fuel Filter Life and hold Reset to bring it back to 100%. Some trucks only accept the reset after a key-off / key-on cycle.
Frequently Asked Questions
Q: Will this cap fit a 2024 Silverado 1500 with the 3.0L Duramax?
A: Yes. The 2020-2026 Silverado 1500 and Sierra 1500 with the 3.0L LM2 or LZ0 Duramax use the same fuel filter housing (GM 13539472) and the same TP1015 element as the 6.6L L5P, so the cap threads, the 36mm hex and the O-ring groove are identical.
Q: Why do most listings say this cap only fits the 2500HD and 3500HD?
A: Because the 6.6L L5P was the first and largest market for this cap, so sellers list it under the heavy-duty trucks. The 3.0L LM2 and LZ0 use the same housing and the same TP1015 filter, so the cap fits both families.
Q: What torque should the cap be tightened to?
A: 25 N·m, which is 18 ft-lb. Use a torque wrench rather than guessing — overtightening pinches the O-ring and can seize the cap on the housing threads. The small drain screw takes only 2 N·m / 1.5 ft-lb.
Q: Are the O-rings included with the cap?
A: No. This listing is the housing cap only — the O-rings come in the ACDelco TP1015 filter box. Fit the new filter at the same time as the cap, seat the large O-ring in the machined groove below the cap threads (never on the threads), and lubricate it with clean diesel before installing.
Q: Do I need to replace the O-rings every time I change the filter?
A: Yes. O-rings take a permanent set once they have been compressed under heat, so a reused ring seals poorly even when it looks intact.
Q: Does the aluminum cap need a different socket than the factory cap?
A: No. Both use a 36mm socket, and a 1-3/8" socket also fits. A 32mm socket, which is often quoted for older Duramax filters, does not fit this housing.
Q: Will this cap fit a 2016 or older Duramax?
A: No. Trucks through 2016 with the LML or LGH engine use a spin-on TP3018 canister and do not have a threaded housing cap.
Q: Can the aluminum cap crack like the plastic one?
A: The cap is machined from solid 6061-T6 billet rather than molded, and aluminum does not become brittle from heat cycling the way glass-filled nylon does, so it does not develop the stress cracks that make plastic caps weep.
OEM Cross-Reference
Number
Type
134001
Fuel filter housing cap (this part)
13539472
GM housing the cap threads into
TP1015 / 13539108 / 23304096 / 22937279
Filter element the cap holds
Related Reading
Your L5P's Plastic Fuel Filter Cap Is a Ticking Time Bomb — Here's the Fix
Duramax 6.6L L5P Fuel Filter Replacement: Complete Step-by-Step Guide
Manufactured under an ISO 9001:2015 quality management system and an IATF 16949:2016 automotive quality management system.
